de.unikassel.android.sdcframework.service
Class SDCServiceConnectionHolder

java.lang.Object
  de.unikassel.android.sdcframework.service.SDCServiceConnectionHolder

All Implemented Interfaces:

LifeCycleObject

public class SDCServiceConnectionHolder
extends Object
implements LifeCycleObject

Implementation of life cycle dependent SDC service connection holder.

This class can establish, destroy and observe a connection with the SDC service. It does act based on the activity life cycle, thus the connection is established on creation and destroyed on destruction. The related methods have to be called by the controlling activity. To get notifications about related events, the activity should implement the ServiceConnectionEventReceiver interface.

Nested Class Summary

static interface

SDCServiceConnectionHolder.ServiceConnectionEventReceiver Interface for receivers of service connection events

Field Summary

private List<SDCServiceConnectionHolder.ServiceConnectionEventReceiver>	listEventReceivers The event receiver list
private ISDCService	sdcService The service interface
private boolean	serviceAvailable The service availability state flag
private Class<?>	serviceClass The service class
private ComponentName	serviceComponent The service component name
private ServiceConnection	serviceConnection The service connection

Constructor Summary

SDCServiceConnectionHolder(Class<? extends SDCService> serviceClass)
Constructor

SDCServiceConnectionHolder(SDCServiceConnectionHolder.ServiceConnectionEventReceiver receiver, Class<?> serviceClass)
Constructor

Method Summary

void	addEventReceiver(SDCServiceConnectionHolder.ServiceConnectionEventReceiver receiver) Method to add an event receiver
private ISDCService	getSdcService() Getter for the sdcService
ComponentName	getServiceComponent() Getter for the serviceComponent
void	onCreate(Context applicationContext) Creation method
void	onDestroy(Context applicationContext) Destroy method
void	onPause(Context applicationContext) Pause method
void	onResume(Context applicationContext) Resume method
void	removeEventReceiver(SDCServiceConnectionHolder.ServiceConnectionEventReceiver receiver) Method to remove an event receiver
private void	setSdcService(ISDCService sdcService) Setter for the sdcService
void	setServiceComponent(ComponentName serviceComponent) Setter for the serviceComponent

Methods inherited from class java.lang.Object

clone, equals, finalize, getClass, hashCode, notify, notifyAll, toString, wait, wait, wait

Field Detail

serviceConnection

private final ServiceConnection serviceConnection

The service connection

serviceAvailable

private boolean serviceAvailable

The service availability state flag

sdcService

private ISDCService sdcService

The service interface

listEventReceivers

private final List<SDCServiceConnectionHolder.ServiceConnectionEventReceiver> listEventReceivers

The event receiver list

serviceClass

private final Class<?> serviceClass

The service class

serviceComponent

private ComponentName serviceComponent

The service component name

Constructor Detail

SDCServiceConnectionHolder

public SDCServiceConnectionHolder(SDCServiceConnectionHolder.ServiceConnectionEventReceiver receiver,
                                  Class<?> serviceClass)

Constructor

Parameters:

receiver - the event receiver

serviceClass - the service class

SDCServiceConnectionHolder

public SDCServiceConnectionHolder(Class<? extends SDCService> serviceClass)

Constructor

Parameters:

serviceClass - the service class

Method Detail

getServiceComponent

public ComponentName getServiceComponent()

Getter for the serviceComponent

Returns:

the serviceComponent

setServiceComponent

public void setServiceComponent(ComponentName serviceComponent)

Setter for the serviceComponent

Parameters:

serviceComponent - the serviceComponent to set

onResume

public void onResume(Context applicationContext)

Description copied from interface: LifeCycleObject

Resume method

Specified by:

onResume in interface LifeCycleObject

Parameters:

applicationContext - the application context

onPause

public void onPause(Context applicationContext)

Description copied from interface: LifeCycleObject

Pause method

Specified by:

onPause in interface LifeCycleObject

Parameters:

applicationContext - the application context

onCreate

public void onCreate(Context applicationContext)

Description copied from interface: LifeCycleObject

Creation method

Specified by:

onCreate in interface LifeCycleObject

Parameters:

applicationContext - the application context

onDestroy

public void onDestroy(Context applicationContext)

Description copied from interface: LifeCycleObject

Destroy method

Specified by:

onDestroy in interface LifeCycleObject

Parameters:

applicationContext - the application context

addEventReceiver

public void addEventReceiver(SDCServiceConnectionHolder.ServiceConnectionEventReceiver receiver)

Method to add an event receiver

Parameters:

receiver - the event receiver

removeEventReceiver

public void removeEventReceiver(SDCServiceConnectionHolder.ServiceConnectionEventReceiver receiver)

Method to remove an event receiver

Parameters:

receiver - the event receiver

setSdcService

private final void setSdcService(ISDCService sdcService)

Setter for the sdcService

Parameters:

sdcService - the sdcService to set

getSdcService

private final ISDCService getSdcService()

Getter for the sdcService

Returns:

the sdcService
